| Zero VA Gage Head combined
with STD. expsnding Ball Arbor for
concentricity Bore check. |
 |
 |
VC Sweep Unit is
used with Zero Hydraulic Arbor which is
expanded in top bore. Alignment is then
checked with Sweep Unit. |
 |
VA Gage Unit is
combined with Zero thread pitch Arbor to
check concentricity. |
 |
Zero Model VE
used with Instrument Type Inspection
Equipment. |
 Model D-A-P with front pilot
and large stop
|
 Model VC with Expanding
Split Collet
|
Model VC-1 With Pressure Pad
for Concentricity Check
|
 Zero Maxum Unit Checks
Squareness
|
 Model VA with
thread locator to check concentricity
|
 Model VA-3
|
 Qualifying gage
using model VC with retracting button for
different size holes in similar castings.
|
 Model VC-1 with
large stop
|
 Relation gage
using Zero differential gages which find
true hole position with only 90° sweep.
|
 Zero Maxum
units check hole locations
|
 Model M-P
with push type collet for concentricity
of two bores and squareness of a face.
|
 Special Model
VJ-5 to check squareness
|
 Special Model
VC-1 with retracting probe and stop pin
also with set master attached
|
 Hole location
gage using a model VC and a model VC-5
|
